Expected Delivery Round 4: November/December 2024 (before Christmas)
QwertyKeys
Neo80 ISO/ANSI Keyboard Kit [Preorder]
Neo80 - Spray-Coated Version 80% TKL ISO+ANSI Mechanical Keyboard Kit
The Neo80 from QwertyKeys is a simple and elegant 80% (TKL) Mechanical Keyboard Barebone Kit.
The Backside Weight is kept very minimalistic and clean. The front side offers a nice Neo Orbit LED element above the arrow keys.
All PCBs offer support for ANSI and ISO layouts. The Tri-Mode PCB includes two 2200mAh batteries, supports 2.4 GHz wireless and Bluetooth in addition to the cable connection. The firmware is based on QMK and can be configured via VIA.
The Neo80 has various mounting options including gasket mount, rubber O-ring mount and sandwich mount.
Innovative magnetic connectors and contacts eliminate the need for screws during construction!
Available with Aluminum, FR4, POM, PC and Carbon Fiber Plate.
Hard ———————————————> Soft
Carbon Fiber > Aluminum > FR4 > POM > PC
Clack ———————————————> Thock
Carbon Fiber > Aluminum > FR4 > POM > PC
All information about this keyboard can be found on the official QwertyKeys product page.
Extra Parts available.
Specifications:
- 80% TKL Layout Aluminium Case
- WK (with Windows Key) or WKL (no Windows key)
- ISO and ANSI multilayout support!
- RGB Orbit Logo on the front
- Minimalistic backside weight
- Gasket, O-Ring and Sandwich Mount
- Innovative magnetic connectors as well as ball-catch mechanism ensure screwless design
- The Tri-Mode PCB supports Wired, 2.4 GHz wireless and Bluetooth connections.
- South facing hot-swap sockets (some rotated for multi-layout support)
- Includes:
- Neo80 Top & Bottom Case / PCB / Weight & Plate of choice
- Preinstalled external Weight
- Tri-Mode PCB includes two 2200mAh batteries and 2.4GHz USB Dongle
- Poron Case Foam, PE Foam, PCB Foam
- USB-C Daugtherboard preinstalled
- Gasket Jacks & Gasket Socks, Gummy O-Ring (30 duro)
- Free gifts (no warranty and no guarantee of being included)
- Keyboard carrying case
- 1x Keycap & Switch Puller and Screwdriver
- 1x Set of 80% PCB Clip-In Neo Stabilizers
- USB-C Cable
This product is a barebone keyboard kit without Switches and Keycaps, these need to be aquired separately. The oxidation of copper weights is unavoidable due to the characteristics of these materials.
