Keyboard Plates

Keyboard Plates

Plates shape how your keyboard feels and sounds. Here you'll find them individually in various materials – each material with its own flex and sound character. That way you can tune your board to exactly the typing feel you want.

Filters

Sort by:

2 products

MK60 Plate, FR4, black, top view on grey background
MK60 Plates Sale price€20,00 EUR
MK65 Plate, FR4, black, top view on grey background
MK65 Plates Sale price€20,00 EUR

Keyboard plate: material, flex and layout

The plate sits between keycaps and PCB. The switches snap into its cutouts, the plate keeps them straight and also holds plate-mount stabilizers. Because the cutouts define where switches can sit, a keyboard plate often determines the layout.

Material: soft to stiff

PP is very soft, springy and sounds deep. Polycarbonate and POM are a step above, FR4 is the neutral middle, aluminium feels firm and sounds brighter. Brass and steel are stiffer and heavier still. Thicker plates are also stiffer. How the plate interacts with mounting and PCB is covered in the guide gasket mount and sound.

Our MK plates

We carry two plate products: the MK60 plates for the MK60MX and GH60-standard PCBs, and the MK65 plates for MK65MX and MK65MXW. Both come in PP, aluminium and FR4 as universal plates with ISO and ANSI, split left shift, split backspace, stepped caps lock and 6.25u and 7u spacebar.

Universal or fixed layout

Universal plates have cutouts for several options and are flexible. Where cutouts overlap, some material is missing, so the plate tends to be slightly less stiff. Fixed-layout plates are cut more cleanly but tied to one variant. Always check that layout, spacebar length and stabilizer type match your PCB. The stabilizers and keyboard PCBs help with that. In-stock items ship from Germany within one working day.
