Kraze - 65% ISO+ANSI Mechanical Aluminium Keyboard Kit

Kraze × MonacoKeys — the Kraze with full DE-ISO support

The Kraze is a 65% custom keyboard by Nuxros, produced in collaboration with Kezewa — and on this product page, you get it with our in-house MonacoKeys MK65 PCBs: either as MK65MX (wired) or MK65MXW (tri-mode wireless). Both PCBs were developed by us with a clear goal: full ISO and ANSI multilayout support for the Kraze — so you can build this exceptional custom board in DE-ISO layout (with umlauts and ß) without having to switch to ANSI.

65% layout — compact and workflow-friendly

The Kraze uses the popular 65% format — compact, but with preserved arrow keys and an additional column on the right with navigation cluster. Perfect balance between 60% and TKL layouts, ideal for heavy typists, programmers, and office workflows that don't want to give up arrow keys.

Wired or wireless — the choice is yours

Choose between the two PCB variants at checkout:

Wired - MK65MX Wired Hot-Swap PCB

The wired variant with USB-C connection:

• Per-key RGB LEDs — each key individually configurable
• QMK firmware with RP2040 chip (firmware source code will be released)
• VIA and VIAL configurable — key mapping, macros, and layers directly in the browser
• ISO + ANSI multilayout support
• 6.25U and 7U bottom row
• Split backspace, split left shift, stepped capslock
• EZMate connector — more precise and reliable than classic JST connectors
• Includes Unified C5 daughterboard with matching EZMate-to-JST-SH cable

Wireless - MK65MXW Tri-Mode Hot-Swap PCB

The wireless variant with full tri-mode connectivity:

• USB-C, 2.4 GHz wireless, and Bluetooth — flexibly adaptable to your workflow
• Per-key RGB LEDs
• QMK firmware with STM32 chip (firmware source code will be released)
• VIA configurable
• ISO + ANSI multilayout support
• 6.25U and 7U bottom row
• Split backspace, split left shift, stepped capslock
• Includes matching daughterboard and batteries — the battery connection runs through the daughterboard

Maximum layout flexibility

Both MK65 PCBs support both ISO and ANSI layouts on a single PCB — with extensive multi-layout options:

• ISO + ANSI layout support — perfect for DE-ISO, UK-ISO, or US-ANSI
• Split left shift + big ANSI left shift — flexible depending on keycap set
• Split backspace + regular backspace
• Stepped capslock — for vintage and SA/MT3 keycap sets
• 6.25U and 7U spacebar — compatible with most keycap sets

PCBSnap mount — the Kraze as the first keyboard designed for it

The Kraze uses PCBSnap as its mounting option — a mounting method developed jointly by Nuxros and GEON to improve classic O-ring mount keyboards. PCBSnaps are therefore compatible with many other keyboards originally designed for O-ring mounting — however, the Kraze is the first keyboard designed specifically for this mounting style: every detail in the case, from the cutouts to the tolerance chain, is optimized for PCBSnap.

PCBSnap replaces the classic O-ring mount: instead of the PCB being supported by an O-ring between case halves, it's "clamped" directly into the case structure via the snap elements. The result is a distinctive sound and feel character with precise bottom-out, clearly defined keystrokes, and characteristically consistent acoustics across all keys — neither too soft (like pure gasket builds) nor too hard (like classic top mounts).

Six color variants

We offer the Kraze in the following color variants:

• Ruby Red — rich, lively red with statement character
• Vintage — muted, warm vintage tone
• Black — the timeless, professional classic
• RAW — untreated, natural aluminum with clear coating against oxidation
• Purple — strong, characterful purple
• Cloud Dancer — soft, light off-white

Plate options

The package includes the PC plate as standard — delivering a balanced, slightly softer typing feel with a warm sound profile that pairs excellently with the PCBSnap character. As optional add-ons, PP (maximum flex, very soft) and aluminum plates (firmer, more precise bottom-out) are also available.

Battery compartments — thoughtfully filled

The Kraze features two battery compartments in the case bottom. With the wired variant (MK65MX), 2 foam fillers for these compartments are included. With the wireless variant (MK65MXW), the batteries are installed instead of the foam fillers. If you want additional weight and a more planted feel, you can alternatively order the stainless steel battery compartment weights as an add-on.

Premium craftsmanship in detail

• CNC-machined aluminum case with aluminum bottom weight
• PCBSnap mounting — developed jointly by Nuxros and GEON; the Kraze is the first keyboard designed specifically for it
• 7° typing angle with 18.5 mm front height
• Dimensions: 313 × 109 mm

About the designer — NuxrosKB

Nuxros is one of the most well-known custom keyboard designers from the Vietnamese community and has built a name with projects like the Krush65 for high-quality custom builds at fair prices. The Kraze is his most ambitious collaboration to date and extends the Krush65 concept. The Kraze is manufactured by Kezewa. The MK65MX and MK65MXW PCBs were developed by MonacoKeys (design: Quark) — we also make them available to other vendors.

Looking for the Kraze with the native Nuxros PCB?

The Kraze with the native Kraze PCBs (solder, ANSI wired hot-swap, ANSI tri-mode), the GEON Venom65 HE RGB, or as a Metapulse EC ready-to-build bundle is available as a separate listing in our store.

Who is the Kraze × MonacoKeys edition for?

• DE-ISO users looking for a high-quality 65% aluminum build in their familiar layout — with umlauts and ß
• Custom build enthusiasts who want to combine PCBSnap mounting with maximum layout flexibility
• Wireless setup designers looking for a tri-mode setup with ISO+ANSI flexibility via the MK65MXW
• RGB lovers who want per-key lighting in a premium custom build
• Layout experimenters who want to find their perfect configuration with split backspace, split left shift, and stepped capslock
• QMK power users who appreciate open-source firmware with VIA/VIAL convenience

Note: The Kraze × MonacoKeys edition is a barebone kit. Switches and keycaps are not included and must be purchased separately.
