Neo80CU - 80% TKL ISO+ANSI Mechanical Aluminium Custom Keyboard Kit [Preorder]

€239,00 Pre-order
Tax included. Shipping calculated at Checkout.

Neo80 Cu – 80% TKL ISO+ANSI Mechanical Aluminum Custom Keyboard Kit

The Neo80 Cu combines premium materials, refined acoustic engineering, and modular flexibility in a stylish 80% layout. Designed for keyboard enthusiasts seeking a high-end custom board that unites performance, aesthetics, and sound.

Key Features

80% Layout (TKL)
The 80% layout offers a well-balanced mix of compactness and functionality – perfect for desk efficiency while saving valuable space.

Premium Materials & Weight

  • Top case made from anodized aluminum in multiple color options

  • Bottom case available in copper or brass

  • Final build weight: approx. 4.5 kg, providing stability and a solid typing experience

Acoustics & Sound Optimization

  • Partitioned Acoustic Chamber Design reduces hollow sound

  • Integrated Forcebreak Pads at contact points minimize metallic vibrations and resonance

  • No foam required – the design delivers the signature copper bottom sound that fans of the series appreciate

Mounting & Suspension Systems

  • Three mounting options: Poron Gasket Mount, Silicone Gasket Mount, and Top Mount

  • Poron gaskets sit in specially designed grooves inside the case, allowing installation and replacement without adhesives

Plate Options & Flexibility

  • Options: Plateless, Aluminum (with flex cut & polished chamfer), Carbon Fiber, PP, and PEI – each offering unique sound and feel

  • The aluminum flex plate features integrated spring joints and edge chamfers for reinforcement and acoustic tuning

Electronics & Connectivity

  • Available PCBs:
     • Tri-Mode (USB-C, Bluetooth, 2.4 GHz) – Hot-swap, supports both ANSI and ISO layouts
     • Wired Hot-Swap – ANSI layout only
     • Solder PCB with Mill-Max support

  • Polling rate: 1000 Hz (USB & 2.4 GHz), 125 Hz (Bluetooth)

  • Full NKRO supported

  • No per-key RGB lighting – instead, refined accents like the Star Ring Accent Light

Design & Visual Highlights

  • Star Ring Accent Light on the front: layered aluminum with a mirrored steel ring, creating the impression of a floating planet

  • Three-tone design (different material colors/finishes) for a premium look

  • Compass-inspired Cu logo centered on the rear weight

Specifications & Dimensions

  • Typing angle: 8°

  • Front height: 18 mm

  • Case dimensions: approx. 355.5 × 134 mm

  • Supported layouts: WK / WKL

  • Top case finishes: Anodized Silver, Slate Blue, Teal, Black, Taupe Grey, Dusty Rose, Jade, Ruby Rose, Mont Blanc

Included in the Kit

  • Case with selected PCB + plate combination

  • Poron case foam, silicone gaskets, top mount screws, positioning silicone, rubber feet, spare screws

  • Tri-Mode versions: two pre-installed 2200 mAh batteries

  • Wired & solder versions: filler material (stainless steel or foam) in the battery compartment

  • Accessories: Carrying case, keycap & switch puller, screwdriver, clip-in NeoStabilizers, USB-C cable

Benefits & Use Cases

  • Sound lovers & typing enthusiasts will appreciate the tuned acoustic dampening concept and the solid copper foundation.

  • Modding & tuning fans enjoy the flexibility to choose and optimize mounting styles, plate materials, and PCB options.

  • High-end users seeking both function and design: the mix of refined materials, visual accents, and robust construction makes the Neo80 Cu a true statement piece.

  • Professional environments (office, studio, long-term use) benefit from reliable connectivity (USB & wireless), NKRO, and rock-solid build quality.
Please note:
  • Because of its properties, PEI plates may not be perfectly flat after processing. Slight unevenness is normal for this material.
  • Since the top-mount screws are fixed through the plate, choosing a solder PCB with a plateless configuration makes top-mounting unavailable.
  • Renders are for reference only. Please note that actual product colors may vary under different lighting conditions. Color differences between the render and the actual product will not be considered a quality issue.
  • Dusk are random mixes of gradients, so the result on each unit may vary.
  • Dusk features random gradient mixtures, making each unit unique.
  • Specific color selections for Dusk are not available.
  • Dusk colors may include single or multiple variations as shown in the render, with varying shades and intensities.
  • Purchase indicates acceptance of the above terms.
PCB Layouts

Specifications
  • Typing angle：8 degree
  • Front height：18 mm
  • Size：80% TKL, 355.5mm * 134 mm
  • Layout: WK/WKL
  • Weight： Around 4.5 kg after assembly

Tri-mode ANSI Hotswap PCB (Non-flex Cut)

  • 1.6mm thick
  • Support USB-C, Bluetooth, and 2.4GHz connection
  • Support only ANSI layout
  • NKRO
  • Polling rate: 1000Hz in wired and 2.4GHz mode; 125Hz in BT mode
  • NO Per-key RGB

Tri-mode ISO Hotswap PCB (Non-flex Cut)

  • 1.6mm thick
  • Support USB-C, Bluetooth, and 2.4GHz connection
  • Support only ISO layout
  • NKRO
  • Polling rate: 1000Hz in wired and 2.4GHz mode; 125Hz in BT mode
  • NO Per-key RGB

Wired Hotswap PCB (Non-flex Cut)

  • 1.6mm thick
  • USB-C connection only
  • Support only ANSI layout
  • NKRO
  • Polling rate: 1000Hz
  • NO Per-key RGB

Solder PCB (Non-flex Cut)

  • 1.6mm thick
  • Mill-max compatible
  • USB-C connection only
  • Support both ANSI and ISO layout
  • NKRO
  • Polling rate: 1000Hz
  • NO Per-key RGB
Content List

Keyboard Case

  • For orders with tri-mode PCBs, two 2200 mAh batteries come pre-installed in the battery compartment
  • For orders with wired PCBs, two stainless steel fillers come pre-installed in the battery compartment
  • For orders with solder PCBs, two foam fillers come pre-installed in the battery compartment. （If you purchase the stainless steel battery compartment fillers in the extra part page, foam fillers will no longer be included.）

PCB kit

  • PCB of your choice
  • 1x PE sheet
  • 1x PCB Foam
  • Tri-mode PCB comes with a 2.4Ghz dongle

Plate of your choice

Poron case foam

PCB Daughterboard and magnetic connectors - installed

9x Silicone Gaskets, 9x long Poron gaskets, 18x short Poron gaskets and Top-mount mounting screws

4x Positioning silicone(grey)

Rubber feet in 2 colors

Backup screws

  • Keyboard carrying case
  • Keyboard pouch
  • 1x Keycap & Switch puller
  • 1x Screwdriver
  • 1 set of PCB clip-in NeoStab
  • USB-C cable

Neo80 Cu

The Neo80 Cu is built around the beloved 80% layout, a proven favorite among professionals and enthusiasts who prioritize efficiency and functionality. This layout offers the perfect balance between compact design and practical usability, making it ideal whether you're upgrading your workspace or seeking a reliable daily driver.

Star Ring Accent Light
Elegant, Floating Silhouette
3D Curved Weight
Three-toned Design
1 / 4

Full Copper & Brass Bottom

Despite its large 80% layout, we've maintained the Cu series's signature all-copper bottom design—bringing the keyboard's total weight to approximately 4.5 kg when fully assembled.

Does weight matter?

Acoustic Chamber Design with Integrated Forcebreak

Like most Neo keyboards, the bottom case features a partitioned acoustic chamber to minimize hollowness. Forcebreak pads at all contact points reduce vibration and metallic noise, and combined with the copper base, deliver the deep, clean "copper bottom" typing sound that Neo fans love, without any foam.

The Star Ring Accent Light

Inspired by massive celestial bodies, whose gravity warps surrounding space, the Neo80 Cu's top case features a multi-layered "star ring" light that captures the brilliance of a planet against the dark night sky. The central "planet" features a triple-etched aluminum finish, surrounded by a mirrored stainless-steel ring, creating a striking "floating planet" effect.

Weight Design

On the back, the intersection of the weight and the bottom case features a carefully sculpted slope that softens transitions. The compass-inspired Cu series logo sits in the center, showcasing the iconic symbolism of the Neo brand.

Mounting Structure

Poron Gasket Mount + Silicone Gasket Mount + Top Mount

We’ve integrated both a Poron gasket structure and the traditional silicone gasket mount into the Neo80 Cu. Unlike conventional Poron gaskets that require adhesive mounting, our design features custom grooves in the bottom case that securely hold the Poron gaskets in place—allowing for easy replacement and exceptional long-term durability. Note: Since top-mount screws are fixed through the plate, top-mounting is not possible when using a soldered PCB without a plate.

New Color in Real Shots

Not only are we bringing back the fan-favorite Teal from the Neo series, but we’re also introducing a stunning lineup of fresh colors — Slate Blue, Taupe Grey, Dusty Rose, Jade, and Ruby Rose, giving you even more ways to make your keyboard truly yours.

Ruby
Rose

Taupe
Grey

Jade

Dusty
Rose

Designed with Vision, Defined by Excellence

Mastery in Every Detail

Design is woven into every inch of our work, from the Star Ring Accent Light at the front to the compass-inspired on the weight. Within every small space lies an abundance of thoughtful artistry. We refine every detail with uncompromising precision.

Uncompromising in Materials

Every material choice is made with intention. From the harmony of an aluminum top case and copper bottom case to the introduction of multiple plate options, each element is thoughtfully considered. All to create a keyboard that feels truly your own.

Engineered with Purpose

Our structural design embodies our deepest commitment. The case features an Acoustic Chamber for refined sound, paired with an integrated force break to minimize unwanted resonance. With three mounting options, the keyboard can be tailored until it feels uniquely yours.
